GOBO DERBY

SPL-RG-309A

1. 8pcs 3W R,G,B,Y LED for derby with moving gobos through 15 lens
2. 8pcs 3W UV LED at both side for decoration
3. 2pcs 3W white LED at bottom with strobe and wash effect
4. RG laser with 12 built-in laser patterns(no laser for SPL-LED-309B)
5. IR remote control for easy use
6. Perfect light for home party, small stage, decoration and so on.

Detailed Introduction

Power

Input voltage：AC100-240V 50/60Hz

Power consumption：60W

Fuse：T2A/250V


 Fixture

IP rating：IP20

Cooling method: fan cool

Max ambient temp：45℃

Case color：black


 LED

Spot Derby: 8*3W single color LED, R2/G2/B2/Y2

Strobe: 2*3W white LED

UV: 8*3W UV LED

Laser: 1*80mW 650nm red +30mW 532nm green (no laser for SPL-LED-309B)

Average lifespan: 50,000 hours

 Control

DMX channel：2/10CH (2/8CH for SPL-LED-309B)

DMX connector：3Pin XLR input/output

Power connector: IEC input

control mode：DMX/master-slave/auto/sound

IR remote control for easy use

Built-in laser pattern: 12pcs

3B laser safety class with key switch and interlock

LED display

8 small gobos (2 gobos for each R,G,B,Y）

3*5 lens for gobo derby


 Color effect

Color：R,G,B, Y, W,UV

Dimming：0-100%

Strobe：25/S


 Dimension

Product dimension: 230*245*191.5mm

Net weight：2Kg
