3in1 effect light

SPL-RG-306C

1. 2*10W 4in1 LED for derby effect.
2. RG laser with 36 built-in laser patterns, can edit pattern via software and make zoom, rotation, move, track effects.
3. 7 SMD LED rings, with separate ring control, strobe, dim and wash effect
4. IR remote control for easy use

Detailed Introduction

Power

Input voltage:AC100-240V 50/60Hz

Power consumption:50W

Fuse:T2A/250V


 Fixture

IP rating:IP20

Cooling method: fan cool

Max ambient temp:45℃

Case color:black plastic case


 LED

Derby LED: 2*10W RGBW 4in1 LED

Strobe LED: 105* RGB 3in1 0.2W SMD5050 LED

Laser: 1*100mW 650nm red +30mW 532nm green

Average lifespan: 50,000 hours

Color temperature:6500K

 Control

DMX channel:2/14CH

DMX connector:3Pin XLR input/output

Power connector: IEC input/output

control mode:DMX/master-slave/auto/sound

Series connection:16PCS at most

Separate ring control for 7 SMD rings

Built-in laser pattern: 36pcs

IR remote control for easy use

3B laser safety class with key switch and interlock

LED display


 Color effect

Color:R,G,B, W full color mixing

Dimming:0-100%

Strobe:25/S


 Dimension

Product dimension: 298*216*142mm

Net weight:5.2Kg

Carton dimension: 60 X 53 X 31.5cm (2pcs)

G.W.: 12KG
