3-8W RGB Full color animation laser light

SPL-RGB-246

Features:
1.RGB full color laser light with high speed scanner to create beam show, anlogo show and text show
2.Support laser show software,e.g.Panglin,Phoenix,Mamba
3.Use SD card to save patterns and then press the buttons on LCD display or use DMX controller to select patterns saved in SD card.
4.Max 16units work synchronously under the control of computer
5.Safety capacity:design according to security and good performance, safe to human and environment.
6.Auto close light when scanner has trouble
7.Applicable for disco, club, KTV, pub, Bar, familiy party etc

Detailed Introduction

Model:SPL-RGB3000-246\SPL-RGB5000-246\SPL-RGB8000-246
Power supply: AC 100-240V 50/60Hz
Power consumption:70W/78W/90W
Total Laser power:3W RGB semiconductor integrated laser/5W RGB semiconductor integrated laser/8W RGB semiconductor integrated laser
Laser class:Class 4
Laser power/Wavelength:SPL-RGB3000-246
                       Red: 500mW/638nm
                       Green: 500mW/520nm
                       Blue: 2000mW/445nm

                       SPL-RGB5000-246
                       Red: 700mW/638nm
                       Green: 800mW/520nm
                       Blue: 3500mW/445nm
                       SPL-RGB8000-246
                       Red: 1200mW/638nm
                       Green: 1300mW/520nm
                       Blue: 5500mW/445nm

Scanning anngle:±30°

Modulation:analog

Control mode:DMX/Auto/Sound/Master-slave/PC

DMX channel:17CH

Internal pattern:256 patterns

SD card:with 1PC SD card

Display:LCD display with knob

IP rating:IP20

N.W.(KG):7.5KG

G.W.(KG):8.2KG

Packing size:39*33*25.5CM(1PC/CN)
