Random color SD Card Animation Laser Light

SPL-RGB-235SD

1.Make laser beam show, animation show and text show
2.Display system use elegant LCD screen ,more beautiful and grateful.
3.Use SD card to save patterns and then Press the buttons on the LCD panel or Use  DMX512 controller to select patterns saved in SD card.
4.It can save 4G data with 96 sets of laser effect at most. Non-repeated patterns last for 5 hours  and the time for each set of laser effect is up to the capacity of SD card.
5.Safety capacity: Design according to security and good performance, safer to human and environment.
6.Auto close light when scanner has trouble
7.Applicable for disco, clubs, KTV, pub, bar, family party etc

Detailed Introduction

Specifications

Laser Diode: Diode Laser/Diode Pumped Solid State Laser(DPSS)

Total Laser Power: 500mw

Laser Class: 3B

Red Laser: Wavelength: 650nm, Laser Power: 150mw

Green Laser: Wavelength:532nm, Laser Power: 50mw

Blue Laser: Wavelength: 445nm, Laser Power: 300mw

Power Supply: 90~250VAC

Frequency: 50/60Hz


Scan System: ILDA 10Kpps~20Kpps

Optical Angle: +/-30°

Play Mode: Sound Active/Auto-Play/Master-Slave/DMX512

Channels: 13

Gross Weight:3.0Kg

Inner  Packing Size:330x260x190mm

Outer Packing Size:65x51x41cm(8pcs)
