Specification:

 Power

Input voltage: AC100-240V 50/60Hz

Power consumption: 320W

Fuse: 6.3A/250V，￠5*20

 Fixture

IP rating: IP20

Cooling method: fan cool

Max ambient temp: 45℃

Case color: black

 Lamp

Lamp: Mingzhe MSD 230W

Color Temp: 8000K

Average lifespan: 2,000 hours

 Control

DMX channel: 16CH

DMX connector: 3Pin XLR input/output

Power connector: PowerCon input

Control mode: DMX/master-slave/auto/sound

Pan: 540º16bits, Tilt: 270º16bits

Precise and fast Pan/Tilt movements

Motorized focus, frost, split color and rainbow effect

3-phase motor for Pan/Tilt, automatic position correction

Static gobo wheel: 13gobos plus open

Static color wheel: 14colors plus open

Prism 1: 8-facet +16-facet rotating, Prism 2: 16-facet rotating

Prism overlay and full color LCD display with 5 buttons

With RMD function and software upload via DMX cable
